Lamborghini P400 Miura Door Windows

Manual crank windows-
used in Miura build #1-275 (P400)
Early P400 style
Late P400 style




Item
Lambo
number
oem details
Notes
Other OEM
applications
comments
glass, driver

3 hole
see above marking for side glass etch
none

glass, passenger

3 hole, tint, light green, 5.75mm thick see above etch


channel, steel , glass attach

1.5mm steel



roller assemblies for track

nylon V pointed rollers, 27mm OD, 5mm bore
7.25mm width, 45 degree taper


roller hardware





plate, steel , glass attach





gasket, glass mounting





hardware, glass attach





gear, cable driver (large gear)

52 tooth cast zinc, right hand cable groove
104mm OD


gear, cable pass (large gear)

52 tooth cast zinc, left hand cable groove



plate, friction cable gear


behind cable gear


stud, cable gear


rivited attachment


pinion gear assembly

12 tooth
gear, spring, housing, shaft, pin


rivets, pinion mount

4mm steel



spacers, pinion mount

steel, 9.3mm length, 8mm OD,



cable

2.5mm steel multistrand cable, approx 2 m



ferules, cable attach

to fit cable
swaged/crushed onto cable ends


pulleys, cable top and bottom

aluminum cast



stud, pulley mount





frame, gearbox

3mm steel plate



frame, top bar

steel



frame, bottom bar

steel



frame. foward bar, grooved

aluminum



frame, rear bar, grooved

aluminum



machine screws, frame corners

6mm flat head steel



bolts, gear plate to foward frame

6mm hex head steel



studs, mounting


fastens frame to door structure, lower


screw, mounting


fastens frame to door structure, upper


handle, window crank

steel , welded hub, punched holes



handle trim, window crank

steel



i need your input to make this a valuble page.


Door glass for P400 are 3 hole with a trimmed front corner.
5 hole power window glass will work in a 3 hole P400 manual window app.

http://www.miuraworkshop.com
